Nylon 66 Tyre Cord Fabric

Product Description:

Dipped Nylon 66 tire cord fabrics are rubber reinforcement materials known for their high strength and excellent fatigue resistance. The dipped structure supports strong tensile retention, controlled deformation under temperature changes, and uniform fiber cohesion, providing dependable reinforcement efficiency across demanding operating conditions.

Inquire Now Add To Cart

Product Details

Tire cord fabric has a very low weft density and looks like a curtain, where the warp bears the load while the weft holds the warp in position. Normally, it can be used in tires, air springs, and rubber products to withstand significant shock loads and strong vibrations.

Dipped Nylon 66 tire cord fabrics are rubber reinforcement materials known for their high strength and excellent fatigue resistance.

Please feel free to contact us for more specifications. We provide customized service, let us know your needs, we will produce for you!

Below are technical specifications for Dipped Nylon 66 tire cord fabrics.

For more specifications please feel free to contact us.

Customization service are available, let us know your requirements, we will produce for you!

ITEM		UNIT	210D/1	420D/1	840D/1	1260D/1	1680D/1
ITEM		UNIT	(235dtex/1)	(470dtex/1)	(930dtex/1)	(1400dtex/1)	(1870dtex/1)
Ave Breaking strength		N/end	30	30	67	98	127
Elongation at Certain load		%	10±2	10±2	7.5±1.0	7.5±1.0	8.0±1.0
Elongation at Certain load		%	(11.2N)	(22.2N)	(22.6N)	(33N)	(44.1N)
Adhesion(H-test)		N/cm	13	20	49	64	78
Breaking Strength CV		%	5	5	5	5	5
Breaking elongation		%	20+3	20+3	20+2	20+2	20+2
Breaking elongation CV		%	7.5	7.5	7.5	7.5	7.5
Dip pick up		%	4.5+1.5	4.5+1.5	4.5+1.5	4.5+1.5	4.5+1.5
Diameter		mm	0.15+0.03	0.27+0.03	0.32+0.03	0.43+0.03	0.50+0.03
Twist	Single(Z)	T/10cm	35+1.5	21+1.5	21+1.5	19+1.0	16+1.0
Twist	Plytwist(S)	T/10cm	/	/	/	/	/
Hot air shrinkage 160℃×2min x 0.05cN/dtex (max)		%	4.5	4.5	4	4	4
Moisture content(max)		%	1	1	0.8	0.8	0.8

ITEM		UNIT	840D/2	1260D/2	1680D/2	1890D/2
ITEM		UNIT	(930dtex/2)	(1400dtex/2)	(1870dtex/2)	(2100dtex/2)
Ave Breaking strength		N/en d	137.2	211.7	280	310
Elongation at certain load		%	8.5±0.8(44.1 N)	8.5±0.8(66.6N)	8.7±0.8 (88.2N)	9.0±0.8 (100N)
Adhesion (H-test)		N/cm	107.8	137.2	156.8	166.8
Breaking strength CV		%	5.0	5.0	5.0	5.0
Breaking elongation		%	20.5±2	21.5±2	22±2	22±2
Breaking elongation CV		%	7.5	7.5	7.5	7.5
Dip pick up		%	5.0+1.0	5.0+1.0	5.0+1.0	4.5+1.0
Diameter		mm	0.53±0.05	0.65±0.05	0.74±0.05	0.78±0.05
Twist	Single (Z)	T/10cm	46±1.5	37±1.5	32±1.5	32±2.0
	Ply twist (S)	T/10cm	46±1.5	37±1.5	32±1.5	32±2.0
Hot air shrinkage160℃×2min x0.05cN/dtex (max)		%	5.0	5.0	5.0	5.5
Moisture content (max)		%	1.0	1.0	1.0	1.0
