EP Belting Fabric

Product Description:

EP belting fabric provides superior performance thanks to its high tenacity, good heat resistance, long service life, low elongation, and excellent adhesion.

Inquire Now Add To Cart

Product Details

Dipped canvas is widely used in various conveyor belts and other industrial applications. According to customer requirements, the company can use different fibers such as polyester, nylon and other raw materials to produce products that meet customer needs. Product features:high strength, soft, anti crimp.

Please feel free to contact us for more specifications. We provide customized service, let us know your needs, we will produce for you!

Item	EP80		EP100		EP125
	Warp	Weft	Warp	Weft	Warp	Weft
Mean breaking strength/(N/mm) ≥	105	45	135	50	160	65
Min breaking strength/(N/mm) ≥	90	35	110	40	130	55
Breaking elongation/% ≤	1.5		1.5		1.5
10%load elongation/% ≤	≥14	≤45	≥14	≤45	≥14	≤45
Heat shrinkage/% ≤	5.0	0.5	5.0	0.5	5.0	0.5
Adhesion/(N/mm) ≥	7.8		7.8		7.8
Unit weight/(g/m2) ≤	310		370		440
Thickness tolerance/mm	土0.05		士0.05		土0.05
Width tolerance/mm	土10		土10		土10

Item	EP150		EP160		EP200		EP250
	Warp	Weft	Warp	Weft	Warp	Weft	Warp	Weft
Mean breaking strength/(N/mm) ≥	200	70	210	70	240	80	310	80
Min breaking strength/(N/mm) ≥	170	60	180	60	215	70	265	70
Breaking elongation/% ≤	1.5		1.5		1.5		1.5
10%load elongation/% ≤	≥14	≤45	≥14	≤45	≥14	≤45	≥14	≤45
Heat shrinkage/% ≤	5.0	0.5	5.0	0.5	5.0	0.5	5.0	0.5
Adhesion/(N/mm) ≥	7.8		7.8		7.8		7.8
Unit weight/(g/m2) ≤	540		560		630		800
Thickness tolerance/mm	士0.05		士0.05		士0.05		士0.10
Width tolerance/mm	士10		士10		土10		士10

Item	EP300		EP350		EP400
	Warp	Weft	Warp	Weft	Warp	Weft
Mean breaking strength/(N/mm) ≥	340	90	390	90	455	95
Min breaking strength/(N/mm) ≥	310	80	365	80	420	85
Breaking elongation/% ≤	1.5		1.5		2.0
10%load elongation/% ≤	≥14	≤45	≥14	≤45	≥14	≤45
Heat shrinkage/% ≤	5.0	0.5	5.0	0.5	6.0	0.5
Adhesion/(N/mm) ≥	7.8		7.8		7.8
Unit weight/(g/m2) ≤	870		1050		1200
Thickness tolerance/mm	土0.10		士0.12		士0.12
Width tolerance/mm	土10		士10		士10

Item	EP450		EP500			EP600
	Warp	Weft		Warp	Weft		Warp	Weft
Mean breaking strength/(N/mm) ≥	500	95		560	125		670	125
Min breaking strength/(N/mm) ≥	470	85		515	110		630	110
Breaking elongation/% ≤	2.0			2.5			2.5
10%load elongation/% ≤	≥14	≤45		≥14	≤45		≥14	≤45
Heat shrinkage/% ≤	6.0	0.5		6.0	0.5		6.0	0.5
Adhesion/(N/mm) ≥	7.8			7.8			7.8
Unit weight/(g/m2) ≤	1250			1350			1950
Thickness tolerance/mm	土0.12			士0.14			土0.16
Width tolerance/mm	土10			士10			土10
